Dosing machine mod. Baby Mix Desktop version

Dosing unit for bi-component resins

The BABY-MIX dosing machine is a versatile and compact machine, suitable for dosing two-component resins,

the drive is pneumatic with a pedal, it has a mechanical adjustment to change the quantity of the mixture delivered.

The possibility of setting the quantity of the mixture:

  1. Gives the certainty that the established weight remains unchanged until a new pre-setting.
  2. It allows to obtain a considerable saving of product avoiding mixture leftover at the end of work.
  3. It provides the operator with a fresh mixture that is easy to use, spread, drain, inject, ecc.

It’s very to easy stop the dosage unit application and it spends a very short time.

The dosage unit, also after some months of work, will be clean and besides it doesn’t need maintenance.

Technical data

Changeable ratio fixed from min. 100 : 10 max. 100 : 100 p.p.
Air supply 4-8 bar
Weight: 10 KG
Epoxy tank 500 cl
Hardener tank 500 cl
Dispensing capacity from 0,5cc to 7cc
Dispensing speed 60 shot/min

Details

  • Pneumatic main board.
  • Desktop version.
  • Disposable static mixer.

Optionals

  • Dispensing gun with flexible hoses.
  • Transfer pumps from row material tanks.
  • Resin heater.
  • Stainless steel tanks.
  • Heated hoses.

Application fields

  • Electric/Electronic
  • Marble
  • Automotive
